ZANDER/SDI ZS1


Flight Computer for Gliders



Glider Computer ZS1 (80mm)

Analog unit ZS1R (57mm)

Direct digital variometer with 0.5...5 seconds response time
Graphic screen with maximum dimensions for cutout 80mm
Flight page with more 20 informations simultaneous without schwitching pages
Help pushbutton providing all necessary explanations for each function
Analog unit with mechanical pointer and additional information on LCD (cutout 57mm)
Remote control from stick grip
TE compensation by TE probe or by computer when connected to static
Graphical display of airspaces, nearest airfields and waypoints
Graphical display of start line and turnpoints with photo sectors
TE compensated glide path calculator
Data base memory for up to 6000 airfields
Wind measurement when circling or in straight flight showing the vector wind
With accelerometer for slow speed warning
Connection from ZS1 to flight recorder GP941 to declare pilot name and task
FAI flight recorder GP941 with 70 hours recording time with 4 seconds recording interval
With Windows software for flight evaluation, glider computer update and airspace editing





GPS Flight Data Recorder GP941
